2 x 100 MVA 220/110/11 kVsub-station at Koppal (Halavarthi)

“Establishing 2x100MVA, 220/110/11KV and 1x10 MVA, 110/11 KV sub-station at Koppal (Halavarthi) in Koppal taluk, Koppal district.- Construction of 110KV Terminal Bay at the existing 110KV sub-station at Koppal.- Construction of 220KV Double LILO line for a route length 0.061Kms.- Construction of 110 KV DC line for a route length 2.933Kms from the proposed 220KV sub-station at Koppal (Halavarthi) to the existing 110KV tapping tower towards existing 110KV sub-station.-Construction of 110KV DC line for a route length 7.383Kms to the existing 110KV Sub-station at Koppal from proposed 220KV sub-station at Koppal (Halavarthi). on Partial turnkey basis including supply of all Materials (Except 11kV Switchgear and Equipment's & Materials already supplied), Erection (Including Civil Works), Testing and Commissioning”

Scope items

• 012 x 100 MVA, 220/110/11 kV and 1 x 10 MVA, 110/11 kV sub-station
• 02110 kV terminal bay at the existing 110 kV Koppal sub-station
• 03220 kV double LILO line, 0.061 km
• 04110 kV D/C line, 2.933 km, to the existing 110 kV tapping tower
• 05110 kV D/C line, 7.383 km, to the existing 110 kV Koppal sub-station
