110/11 kV sub-station upgradeat Aurad with 110 kV D/C LILO
- 110 kV
- KPTCL
- Aurad Taluk
- Bidar
- Completed
Scope of work.
“Up-gradation of 2x5 MVA, 33/11 kV sub-station to 1x10 MVA, 110/11 kV sub-station at Aurad and Construction of 110 kV DC line on DC towers(LILO) from existing 110 kV Santhpur-Dongargoan line to the proposed 110/11 kV sub-station at Aurad for a distance of 4.814 kms in Aurad taluk, Bidar district on Partial Turnkey basis including supply of all matching materials/equipments (excluding 11kV switchgear) and erection (including civil works) of all materials/equipments, testing and commissioning”
- Upgrade of the 2 x 5 MVA 33/11 kV sub-station to 1 x 10 MVA 110/11 kV
- 110 kV D/C LILO on D/C towers from the Santhpur–Dongargoan 110 kV line, 4.814 km
- Sub-station
- 110 kV
- 110/11 kV
- KPTCL
- Aurad Taluk
- Bidar
- Completed
- 2021-22
Aurad Taluk
The location named in the record could not be geocoded, so this project is not placed on the map.
—
—
Bidar district, Bidar — 7 projects, district-level position
